| Cadre | Carbon Front Triangle & Seatstay, Aluminum Chainstay, High Pivot Horst Suspension, 150mm Travel, UDH, Eagle Transmission Compatible, Ride Aligned™ |
| Fourche | RockShox Lyrik Ultimate RC2,160mm Travel, 44mm Offset, E-MTB Rated, Fender Included |
| Amortisseur | RockShox Super Deluxe Ultimate, 230x60mm |
| Manette Arrière | SRAM AXS POD Controller, Discrete Clamp |
| Dérailleur arrière | SRAM X0 Eagle AXS T-Type |
| Pédalier | e*Thirteen e*Race Carbon, 165mm |
| Jeu de pédalier | Bosch BES3 DU |
| Cassette | SRAM 1295 Eagle T-Type, 10-52T |
| Chaîne | SRAM XO Eagle T-Type |
| Frein avant | SRAM Code RSC 4 Piston, Sintered Pads |
| Disque avant | SRAM HS2 220mm |
| Frein arrière | SRAM Code RSC 4 Piston, Sintered Pads |
| Disque arrière | SRAM HS2 200mm |
| Leviers de Frein | SRAM Code RSC |
| Guidon | One Up Carbon, 800mm, 20mm Rise |
| Potence | 6061 Alloy, 40mm Length, 35mm Clamp |
| Tige de Selle | TranzX YSI08FL RAD+ Travel Adjust Dropper, 34.9mm, 125mm (S1), 150mm (S2),170mm (S3), 200mm (S4, S5) |
| Jeu de direction | FSA No.55 Sealed Bearing, 1 1/8″ – 1.8″ Tapered |
| Entretoises de jeu de direction | 2 x 10mm, 1x 5mm |
| Selle | SDG Bel Air V3 Lux Alloy |
| Poignées/guidoline | WTB Wavelength |
| Collier de tige de selle | Norco Alloy Nutted Clamp, 38.5mm |
| Moyeu avant | WTB CZR, 15x110mm Boost, 6 Bolt |
| Moyeu arrière | WTB CZR, 12x148mm Boost, XD, 6 Bolt |
| Jantes | WTB CZR i30 Carbon, 27.5″/32H Rr, 29″/28H Ft |
| Pneu avant | Continental Kryptotal-F Trail Endurance 29″ x 2.4″, Foldable |
| Pneu arrière | Continental Xynotal Enduro 27.5″ x 2.4″, Foldable |
| Axe de roue arrière | Axle Assembly. L174, TL13, M12x1.0 |
| Axe de roue avant | RockShox Maxle Stealth 110×15 |
| Rayons/écrous | WTB CZR |
| Drive Unit | Bosch Performance Line CX, 85Nm |
| Batterie | Bosch PowerTube 750Wh |
| Feature 1 | Bosch Smart System Rim Magnet |
| Feature 2 | Bosch PowerMore 250 Range Extender* (Not Included) * Compatible with S3-5 |
