GÉOMÉTRIE DU CADRE



Geometry & Sizing
Size A. Head Angle B. Seat Angle C. Top Tube D. Seat Tube E. Chainstay F. BB Height G. Stand Over
20 73° 70° 20″ (507mm) 8.8″ (224mm) 13.9″ (352mm) 11″ (280mm) 19.5″ (495.3mm)
Spe
cifications
FRAMESET
Frame 6061-T6 heat-treated aluminum frame with integrated head tube. Internal cable routing, 3D dropouts w/integrated chain tensioners
Fork Full chromoly 1 1/8″ Threadless Steerer w/tapered legs
Colors Black
DRIVETRAIN
Cranks 2-pc Forged Alloy w/ 24mm Hollow Spindle. 165mm
Bottom Bracket Press-Fit BB86, Sealed Bearing
Sprocket 38t Alloy Chainring
Gearing 38/15
Pedals Alloy DX, 9/16″
Chain KMC Z33 1/2 X 3/32″
Cassette 15t Cassette
WHEELS
Tires Kenda “Konversion” tires: 20 x 1.65″ front/20 x 1.50″ rear
Front Hub 36h Alloy Sealed-Bearing
Rear Hub 36h Alloy Sealed-Bearing w/ Disc Cassette Rear
Rims 20″ Alloy 36h, Double Wall
BRAKING SYSTEM
Brake Promax DSK-300 Mechanical Disc Brake w/ 160mm Rotor
Brake Lever Promax XL-373 Two Finger
OTHER COMPONENTS
Grips Micro-Knurl Grip
Handlebar Haro Mini Alloy Bar, 6.5″ Rise
Stem Forged Alloy Top-Load, 45mm Ext.
Headset 1-1/8″ Sealed Threadless
Seat Haro Slim Plastic Pivotal
Seat Post Alloy Pivotal, 27.2mm
Seat Post Clamp Alloy, 31.8mm
Poids 12 kg
Marque

Haro

Choisir une couleur

Bleu

Choisir une taille

PRO

Matière

Aluminium

Pratique

BMX

Haro

Gravel:

SizeInchesCM
474'9 - 5'3150 - 160
515'3 - 5'7160 - 170
545'7 - 5'9170 - 175
565'9 - 5'11175 - 180
585'11 - 6'2180 - 188
606'2 - 6'5188 - 196
